Benefits



bullet

Easy to use medium viscosity adhesive

bullet

Room temperature or elevated temperature cure system

bullet

Supplied in DuoSyringe for easy application

bullet

Standard size is 25ml (50g), with associated mixing nozzles and dispenser (not included)

bullet

Shelf life is 6 months from date of manufacture







  Properties
  Curing

Work life at 23°C

  1 hour

Time to handling at 23°C

   8 hours

Time to full cure

  24 hours @ 23°C

  30 minutes @ 100°C
  Optimum Properties (cured at 100°C for 30')

  Lap shear (Al/Al @ 23°C)

   8 MPa
  Lap shear  (Al/Al after 172 hours @ 150°C)   8 MPa

Lap shear  (Al/Al after 172  hours @ 40°C in water)

   6 MPa
  Resistance @ 23°C)   0.01 Ohm·cm

Resistance after 172 hours @ 150°C

   0.01 Ohm·cm

Resistance after 172 hours @ 40°C in water

   0.01 Ohm·cm
  Operating temperature   -55°C to +150°C
  Colour

  Silver
