Benefits



bullet

Will withstand high temperature steam autoclaving and operate for short periods at 350°C

bullet

High surface energy and very low viscosity.
Readily wets and wicks between optical fibres

bullet

Excellent adhesion to glass fibres as well as metal, ceramic and many plastics

bullet

Outstanding impact and thermal shock resistance

bullet

Very long work life after mixing

bullet

Available in easy-to-use TwinPack or Bulk

bullet

Shelf life is 12 months from date of manufacture




  Properties
  Curing

Work life at 23°C

  12 hours

  (4g in syringe)

Curing schedule (time to full cure)

  30 minutes at 120°C

    5 minutes at 150°C
  Properties before curing
  Mixed viscosity   0.5 ÷ 1 Pa·s
  Surface tension   40 ÷ 44 mN/m
  Optimum properties (cured for 5' at 150°C)

Glass transition temperature

   > 140°C

Thermal expansion

  55 x 10-6 cm/cm/°C
  Density   1.2
  Hardness   92D
  Modulus   2 GPa
  Shrinkage on cure   < 3.5%
  Lap shear (Al/Al)   11 MPa
  Operating temperature

  -60°C to +250°C
